Certification:
CCC, CE, Rina
| SPECIFICATIONS | |
| Dimensions: | 194mm (L) x 186mm (W) x 282mm (H) |
| Total Weight: | 6.5kg |
| Discharge Duration: | ≤14s |
| Protected Volume: | 10 m3 |
| Agent Mass | 540g |
| SYSTEM SPECIFIC DATA | |
| Standard activate temperature (by leaner heat cable): | 70ºC, 85ºC, 105ºC (further temperature range on request) |
| Ignition time: | Within 1s after triggering of the thermistor |
| Storage: | Cool and dry condition |
| Operating ambient temperature: | -30ºC ~ +70ºC |
| Fire class: | A(limited), B and C |
| Product Standard Manufacture Warranty: | 1 year |
| Service Life Years (Normal Environment): | 6 years |
| Service Lige Years (Aggressive Environment): | 3 years |
